Description

Workbook

This A3 Workbook is designed for Engineering Graphics and Design educators and learners for Grade 12.

This EGD Workbook is aligned with the National Curriculum and Assessment Policy Statement (CAPS) as provided by the Department of Basic Education (DBE).

This Grade 12 workbook consists of 11 Modules covering all the required learning material. Each lesson is unique and consists of a question and space to complete the drawing. This workbook aims to help develop the user’s basic and advanced drawing skills through employing freehand and instrument drawings, and include the following to cater for the unique requirements of the DBE:

• Follow the order of the ATP
• Adheres to the required DDE’s per topic
• Progression from easy to difficult exercises
• Question wording aligned with NSC exam standard

Many new worksheets, exercises and improvements have been added to our 2026 edition!

Table of Contents

Grade 12 Workbook – IEB Curriculum 2026

• • Module 1 – Revision / Module 1 – Hersiening
  • Module 2 – Mechanical Drawing / Module 2 – Meganiese Tekeninge
  • Module 3 – Civil Drawings / Module 3 – Siviele Tekeninge
  • Module 4 – Perspective Drawing / Module 4 – Perspektieftekeninge
  • Module 5 – Isometric Drawing / Module 5 – Isometriese Tekeninge
  • Module 6 – Solid Geometry / Module 6 – Vaste Liggame
  • Module 7 – Interpenetration and Development / Module 7 – Deurdringings en Ontwikkelinge
  • Module 8 – Loci (Cam) / Module 8 – Lokusse (Nok)
  • Module 9 – Loci (Mechanism) / Module 9 – Lokusse (Meganisme)
  • Module 10 – Loci (Helix) / Module 10 – Lokusse (Heliks)
  • Module 11 – Transition Pieces / Module 11 – Oorgangstukke
